Ply Separator
Bayrich Ply Separator is a tool used to cut between the plies of the conveyor belt before belt splice preparation. This is helpful when preparing finger-over-finger splices and stepped splices, and for recessing mechanical fasteners.
For the conveyor belt with a thickness of more than 3mm, the heat is not easy to enter the inside of the conveyor belt, which will cause the glue to not melt well. The resulting conveyor belt is not firm. So here you will need a ply separator for separate the belts.
With one handle you can determine the depth you want to split the belt. It is possible to split every layer of the belt and in this way generate two or 3 separations within one belt.
Description
Feature
1. Split PVC, PU Belt up to 1-10mm.
2. High precision separation and easy work with scale; can separate films accurate to 0.05mm.
3. With Scale to adjust the splitting depth max. 130mm
4. Hard alloy steel knife and one complete aluminum body, more durable and sharper.
5. Work more safe with cover.
6. Easy control start/stop with pedal switch.
7. Positive/Inversion control box.
8. No Belt Width limited, belts can be divided into two layers, three layers etc.
9. Can splite side of the belt for side seam preparation -new function.
Technical Datasheet
Bayrich Ply separator has been tested successfully with different belt type. However, this is no guarantee for good results. Fabricating belts does require the operator to master skills and have a certain lever of craftsmanship. Results also depend on good practice, material composition and sharpness of the blade.
Machine Detail
The conveyor belt layerer includes the main body of the layerer, in which there are two transmission rollers, both of which are equipped with eccentric adjustment shafts, which are divided into upper adjustment shaft and lower adjustment shaft.
One side of the ply separator main body is equipped with upper support cover and lower support cover, and the other side is equipped with adjusting cylinder and adjusting arm.
The cylinder body of the adjusting cylinder is hinged on the main body of the separator machine, and the output rod of the adjusting cylinder is hinged with a connecting block, One end of the up-regulating shaft is fixed with the connecting block, and the other end is hinged on the upper support cover.
The up-regulating shaft is driven to rotate by controlling the telescopic output rod. The lower support cover is equipped with a shaft end lifting adjustment device. One end of the down-regulating shaft is set on the shaft end lifting adjustment device, and the other end is fixedly connected with the adjusting arm.
The down-regulating shaft is driven to rotate by controlling the rotation of the adjusting arm, The parallelism of the down-regulating shaft and the layering blade is controlled by the shaft end lifting adjustment device. The above layering machine is easy to operate, high in processing efficiency, high in accuracy and good in layering effect.
Aluminum Alloy Body
Aluminum Alloy Body
Depth Tick Marks
Thickness Tick Marks
High Precision Steel Blade
Aluminum Alloy Body
Main Components
Foot Switch---CHNT
Motor - BONFIGLIOLI (Germany)
Optional Accessories
Step Cutter
Machine Stand
FAQ for Bayrich belt ply separator
Q:1.What is the maximum thickness of Bayrich belt separator machine can splite?
A:10mm PU PVC conveyor belt
Q:2.Can Bayrich splitting machine separate a 1mm thick PU conveyor belt ?
A:Sure can .
Q:3.Can the Bayrich belt layering machine separate layers for overlapping or edge wrapping?
A:Yes. the splitting machine has a new function for cutting steps on pu pvc conveyor belt.
Q:4.Can the Bayrich ply separator separate films from the belt ?
A:Yes,that is ok .you no need to buy films,can easily separate from the PU PVC belt.
Q:5.Can the belt ply separator cut a belt with patterns? For example, Roughtop belt?
A:Sure it can.
Q:6.Can the ply separator ply the belt into 3 layers?
A:If the conveyor be has three or more layers of PU PVC materials, dividing it into three layers is not a problem at all
Q:7.Will belt layering machine result in one side being thin and one side being thick?
A:No, our layering machine has very even layering
Q:8.Is the depth of layering be adjustable?
A:Sure, and our layering machine has a scale display that can be divided very accurately.
