Belt Perforating Machine
Bayrich CNC Belt perforating machine (Hole Drilling Machine) is using for drilling holes of different sizes on the open conveyor belt or Endless belt by rotating. It can perforate on different industrial belt as transmission flat industrial belt, PU belt, PVC belt and rubber belts. Belt thickness from 1mm-10mm and hole size from 2-20mm.
Description
Function of Perforated Conveyor Belt
1. The air suction function can better absorb the product during transportation. Such as printing machinery, box pasting machine, etc.
2. Precise positioning, drilling on the conveyor belt along the horizontal or vertical direction, is used to accurately transport or install accessories, such as the belt of the dumpling machine.
3. The drainage function allows the water on the conveyor belt to flow away smoothly in the transportation of cleaning products. For example, the conveyor belt of the cleaning line bailer.
4. Install the accessories. When installing the fixture, install the screws. The bottom of the screws can be inserted in the counterbore, so that the fixture can be installed without affecting the use of the conveyor belt. Such as grain machinery, elevator, etc.
5. Store materials, such as metal parts grinding equipment.
application areas of perforared conveyor belts
(1) Printing industry
Due to its lightweight nature, paper is not easily fixed during transportation. However, punching holes on the conveyor belt allows it to have an adsorption effect, which can keep the paper flat and free from wrinkles, greatly improving the efficiency of paper printing.
(2) Packaging industry
Perforated conveyor belts can be used in vacuum packaging machines to provide suction or adsorption functions.
(3) Food industry
Food such as dumplings and Wonton are often transported by positioning. The conveyor belt can achieve precise positioning and transmission by processing positioning holes.
Feature
For a long time, hole drilling processes for conveyor belt, rubber belt, air suction belt and PVC belt still mostly adopt the most primitive manual drilling methods. No matter how many holes are charged according to the number of holes or the area of holes, the cost of labor accounts for a large part of the production cost. Bayrich has been committed to the R&D and production of drilling equipment for several years. Now the full-automatic Belt perforating machine (hole punching machine ) came into being.
It has below advantage:
1. Automation. Automatic programming, one key processing.
2. High speed and efficiency, one machine can replace four manual machines.
3. Simple operation, zero foundation, 3 minutes to learn.
4. Intelligent and accurate, the hole and groove are clean and free of burrs.
5. Safe, One-click operation to avoid personal injury.
Technical Datasheet
|
Technical data |
1000mm |
1600mm |
2100mm |
2600mm |
|
Power |
3500W |
3500W |
3500W |
3500W |
|
Voltage |
220V |
220V |
220V |
220V |
|
Air Pressure |
0.5 Mpa |
0.5 Mpa |
0.5 Mpa |
0.5 Mpa |
|
Min. belt thickness |
1mm |
1mm |
1mm |
1mm |
|
Max. belt thickness |
10mm |
10mm |
10mm |
10mm |
|
Speed |
2/Sec. speeding is depends on hole size and distance |
|||
|
Hole size |
φ2-φ20mm (Standard any 3 size from φ2-φ15mm) |
|||
|
Min. endless belt girth |
800mm |
|||
|
Minimum error |
1000mm error 0.1 (The error can be calibrated by program) |
|||
|
Belt width |
≤1100mm |
≤1600mm |
≤2100mm |
≤2600mm |
|
Machine weight |
815kg |
915kg |
1015kg |
1115kg |
|
Machine size |
1950*1000*1600 |
2450*1000*1600 |
2950*1000*1600 |
3450*1000*1600 |
|
Accessories |
Tool carbinet, PE pad |
|||
Machine Detail
Protective Cover
Punch Head And Air Cooling System - In order to preven t the blade from overheating and melting the conveyor belt adhesive layer
Punching Head
Protective Cover of Punching Head - Optional accessories
Programming Interface
Control Panel
Electrical Configuration
Automatic Lubricator
Standard 3 drill size
common questions
fAQ about bayrich belt perforating machine
Q:1.What is the maximum hole diameter that can be perforated on the conveyor belt?
A:the standard hole size can be perforated is 20mm. If you have any other requirements, please let us know.
Q:2.What types of industrial belts are suitable for drilling holes on this machine?
A:Rubber conveyor belt ,pu pvc conveyor belt and pu timing belt
Q:3.How to change the hole size ?
A:Our hole drilling machine change hole size by changing different hole drills.
Q:4.How to set the distance and placement for holes?
A:You can set it up through the screen. Single row and double row can be set.
Q:5.Does the belt perforating machine have a memory function?
A:Yes. no need to reset again when you need making same holes and same distance. There is a function to save records, which can be accessed at any time on the next startup without the need for resetting.
Q:6.What is the minimum circumference of a endless conveyor belt that can be perforated?
A:minimum is 1000mm for an endless conveyor belt
