V Guide Welding Machine
Bayrich V guide welding Machine is using for welding V guide (Profile) on the face or back side of the conveyor belt.
There are two main functions of the conveyor belt welding with V guide. One is to prevent the conveyor belt from running sideways, and the other is to use it as positioning on the bearing surface.
When the V guide is welded to the contact surface of the carrier roller of the conveyor belt, the effect is to make the conveyor belt run accurately, prevent it from running away after a long time, and thus protect the long-term use of the conveyor belt.
When the V guide bar is welded to the load surface of the conveyor belt, it is mainly to prevent the material fall down from rolling. The conveyor belt with V guide bar is mainly used in some food processing, such as egg conveyor belt.
Description
Feature
1. Solid V guide welding gun operation platform, accurate welding V guide position.
2. Multi-group pressing wheel combination, suitable for belts with different widths.
3. The switch can freely adjust the turning direction and speed.
4. The baffles at both ends fix the belt position to prevent the belt from deviation.
5. Self-equipped V guide strip winding and storage device at the bottom.
Technical Datasheet
Guide machine is made of frame, motor, frequency inverter, roller, press pulley, guide pulley, worktable, welding machine etc.
Machine Detail
Barometer and Power
Speed Controller and Air Valve Switch
Welding Gun Holder
Guide mould (6*4, 8*5, 10*6, 13*8)
Welding Gun Holder and Grinding Machine
Belt Block -- Make sure the belt runs straight
Accessories Part for Free
Adjustable Positioning Handle -- 4pcs
Guide Mould - 2pcs (6*4, 8*5, 10*6, 13*8), if you need others, please contact sales.
Welding Gun Holder -- 1pcs
Optional Accessories
Grinding Device -- In order to allow the guide bar to be welded on the Belt Bottom, the fabric layer needs to be grinded first.
Guide Mold -- 17*11, 12*12, 10*10, 25*25 etc.
Welding Gun -- 1600W
1meter Extension Frame -- Contact with the machine to let the machine can be used for 2meter belts.
Pls contact us to see the working video.
common questions
fAQ About Bayrich V guide welding machine
Q:1.Can the V guide welding machine weld v guide same time on both sides of the conveyor belt?
A:Yes, just add a base and welding gun, and you can weld the guide bars on both sides in one time.
Q:2.Can V guide be welded on the back fabric layer of the conveyor belt?
A:Sure, first polish the back of the conveyor belt. Then we can weld it
Q:3.Is the grinding depth of the grinding equipment adjustable?
A:Yes.it is adjustable.
Q:4.What types of V guide can be welded?
A:We generally provide five types of guide wheels, including regular models K6, K8, K10, K13, and K17. If you have any other needs, you can also let us know to customize.
Q:5.Can the V guide welding machine weld V guide in horizontal direction?
A:No, this V welding machine is designed for longitudinal V guide welding. If you need to weld horizontal guide , our other high-frequency welding machine or horizontal guide / cleat welding machine can meet your needs..
Q:6.What should I do if there is burning at the end of the belt?
A:When welding to the tail end of the guide bar, the hot air gun can be hovered at a high position and the temperature of the gun can be cooled using a small gear.
